Size 3 Acrow Prop, 2.59m - 4m + Prop Support
Our new steel acrow props are used in the construction industry for temporary support of ceilings, walls, trenches and for formwork. It will extend between 2.59m (closed) and 4m (fully extended). These props have a painted green finish.
The base plates measure 150 x 150 x 6mm.
We also supply Prop Mates. Acrow props are also available in size 1, size 2, size 3 and size 4. We also stock Mortar Raking Blades for use with our Prop Mates. A full range of u-heads is also available in fixed 4", 6" or 8" or adjustable 4", 6" or 8".
Prop Details:
| Info | Detail |
|---|
| Closed Length |
2.59m |
| Open Length |
4m |
| Weight |
20.2kg |
| Specification |
BS4074 1982 Steel |
| Finish |
Painted Green |
| Outer Diameter / Wall Thickness |
Inner Tube - 48.3mm / 3.2mm (Grade 50c)
Outer Tube - 60.3mm / 3.6mm (St 42)
|
Prop Support Details:
| Info | Detail |
|---|
| Height |
350mm |
| Length |
510mm |
| Width |
170mm |
| Safe Working Load |
340kg
|
| Weight |
5.8kg |
| Maximum Working Height |
3m |
